Hardware Design Portfolio

15 CAD hardware design categories — from health wearables to aerospace systems, industrial PLCs to personal air mobility vehicles. All engineered to run the EmbeddedOS stack. KiCad schematics, Altium designs, Gerber files, BOMs, and datasheets.

15
Design Categories
2
Production Ready
50+
Product Lines
10
Future Concepts

eHealth365

Production
Wearable Health Platform

Four-device wearable health monitoring ecosystem covering ~90% of all health metrics. From cardiovascular vitals to blood chemistry, neural signals to activity tracking.

HEALTH-KEY ULTRAHEALTH-BAND NeuroHEALTH-RINGHEALTH-LAB
MCU
nRF5340 + STM32H7
Connectivity
BLE 5.3 LR
FDA Path
510(k) / De Novo
Sensors
ECG, EEG, SpO₂, CGM
Standard: 510(k) Class II
Learn more
GitHub

eRadar360 / Aegis One

Production
Automotive Safety System

360° automotive safety system fusing 4× 77 GHz FMCW radar, 8× cameras, LiDAR, and V2X. AI threat detection running on EoS.

Front RadarRear RadarSide Radars ×4Fusion ECU
Radar
TI AWR2944 77 GHz
Range
0–250 m, 0.75 m res
Latency
<10 ms threat detect
Standard
ISO 26262 ASIL-D
Standard: ISO 26262 ASIL-D
Learn more
GitHub

eAerospace

Design
Aircraft, UAV & Space Systems

Complete aerospace hardware portfolio from flight computers and avionics to UAV swarm controllers and 1U CubeSat reference designs. All running EoS.

Aircraft ComponentsAvionicsUAV / VTOLCubeSat
MCU
STM32H7, LEON3FT
Bus
ARINC-429, CAN FD
Standard
DO-254, ECSS
Class
IPC Class 3
Standard: DO-254 / ECSS
Learn more
GitHub

ePAM

Design
Personal Air Mobility

Solar-hybrid personal transport — 4-product line. 4-5 seat capacity, solar + water/hydrogen hybrid power. From $28K mass-market EcoCar to $4M suborbital Space Shuttle.

Urban Drone (eVTOL)Space ShuttleEco CarCombo Unit
Power
Solar + H₂ hybrid
Range
0–100 km altitude
Seats
4–5 passengers
Price
$28K – $9M
Standard: FAA / EASA
Learn more
GitHub

eRobotics

Design
Industrial Robots & AMR

Industrial robotics portfolio covering servo-driven arms, autonomous mobile robots, warehouse delivery systems, and agricultural robots. EoS SMP on Cortex-A72.

Robotic ArmsWelding RobotsAMR / AGVCobots
MCU
Cortex-A72 + M4
Control
EtherCAT, PROFINET
Standard
ISO 10218-1, 3691-4
Vision
Stereo + ToF
Standard: ISO 10218-1
Learn more
GitHub

eIndustrial

Design
IIoT & Industrial Electronics

Industrial hardware for temperature, pressure, gas, and flow sensors. PLCs, Modbus gateways, HMI panels, and Edge AI nodes for IEC 61131-3 compliant automation.

PLCsGatewaysHMI PanelsEdge AI Nodes
Protocols
Modbus, PROFIBUS, OPC-UA
Standard
IEC 61010-1, 61131-3
Temp range
-40°C to +85°C
Certif.
CE, UL, ATEX
Standard: IEC 61010-1
Learn more
GitHub

eMedical

Design
Diagnostic & Surgical Devices

Medical hardware portfolio covering diagnostic equipment, surgical devices, patient care systems, and laboratory equipment. All designed to IEC 60601-1 medical-grade standards.

ECG / EEGUltrasoundSurgical RobotsLab Equipment
Standard
IEC 60601-1, ISO 13485
FDA Path
510(k) / PMA
Isolation
BF / CF patient applied
EMC
IEC 60601-1-2
Standard: IEC 60601-1
Learn more
GitHub

eEnergy

Design
Battery, Solar & Power Electronics

Energy hardware portfolio covering battery management systems, renewable energy controllers, and power electronics. EoS manages real-time power flow and safety cutoffs.

BMS ControllersSolar InvertersDC-DC ConvertersSmart Breakers
Standard
IEC 62619, IEC 61730
Voltage
12V – 1500V DC
Power
Up to 250 kW
Certif.
UL 1973, CE
Standard: IEC 62619
Learn more
GitHub

eSmartCity

Design
Urban Infrastructure & Utilities

Smart city hardware for urban infrastructure, utilities, and telecommunications. EoS runs on traffic lights, smart meters, water/gas monitoring, and 5G IoT gateways.

Traffic ControllersSmart Meters5G GatewaysParking Systems
Standard
IEC 62264, IEC 62056
Comms
5G, LoRaWAN, NB-IoT
Protocols
DLMS/COSEM, MQTT
Certif.
FCC, CE, ETSI
Standard: IEC 62264
Learn more
GitHub

eDefense

Design
Tactical & Surveillance Systems

Defense hardware portfolio covering surveillance systems, tactical communications, and protection equipment. All designed to MIL-STD-810 rugged standards.

EO/IR CamerasTactical RadiosMesh NetworksDetection Sensors
Standard
MIL-STD-810, 188, 461
Encryption
AES-256, FIPS 140-3
Temp range
-55°C to +125°C
Shock
40g, 11ms half-sine
Standard: MIL-STD-810
Learn more
GitHub

eConsumer

Design
Smart Home, Wearables & AR

Consumer hardware portfolio covering smart home devices, personal wearables, and augmented reality devices. Matter 1.3 and BLE 5.3 connectivity.

Smart SpeakersAR GlassesSmart WatchesIndustrial AR Helmets
Standard
Matter 1.3, Zigbee
Comms
BLE 5.3, ANT+, Wi-Fi 6
MCU
nRF5340, ESP32-S3
Certif.
FCC, CE, Bluetooth SIG
Standard: Matter 1.3
Learn more
GitHub

eElectronics

Design
PCBs, FPGAs & AI Accelerators

Electronics and semiconductor hardware portfolio covering PCBs, embedded controllers, RF modules, FPGAs, AI accelerators, and emerging quantum technologies.

PCB DesignsFPGA ModulesAI AcceleratorsRF Modules
Standard
IPC-2221, JEDEC
Layer count
2–16 layer PCBs
RF
Sub-GHz to 77 GHz
AI
NPU, FPGA, ASIC
Standard: IPC-2221
Learn more
GitHub

eMining

Design
Autonomous Mining & Construction

Mining, heavy industry, and construction hardware portfolio covering autonomous mining equipment, industrial safety systems, and construction robots.

Autonomous Haul TrucksMine MonitoringGas DetectionConstruction Robots
Standard
ISO 17757, IECEx
Protection
ATEX Zone 1 / 2
Comms
LoRaWAN, 4G LTE, UWB
Sensors
Gas, Vibration, GNSS
Standard: IECEx / ATEX
Learn more
GitHub

eCybersecurity

Design
HSMs, Firewalls & Access Control

Cybersecurity hardware portfolio covering security appliances, physical security, and access control. FIPS 140-3 and CC EAL4+ certified designs.

Hardware Security ModulesFirewallsBiometric AccessPerimeter Sensors
Standard
FIPS 140-3, CC EAL4+
Crypto
AES-256, RSA-4096, ECC
Biometrics
Fingerprint, Iris, Face
Certif.
ISO 27001, FIPS 201-3
Standard: FIPS 140-3
Learn more
GitHub

Future Designs

Concept
Donor-Sponsored Concepts

10 concept-stage hardware products for health, accessibility, climate, and research. Each has a datasheet stub, BOM placeholder, and business plan for donor evaluation.

eVision (blind aid)eHand (prosthetic)eBCI-Lite (EEG)eCubeSat-1U
eVision
Obstacle detection band
eHand
6-DOF myoelectric prosthetic
eFarm
Solar LoRaWAN soil sensor
eCubeSat
1U CubeSat reference design
Standard: Various
Learn more
GitHub

Donor-Sponsored Future Designs

10 concept-stage hardware products for health, accessibility, climate, and research. Each has a datasheet stub, BOM placeholder, and one-page business plan for donor evaluation.

👓
eVision
Obstacle-detection band for blind users
Donor tier: $5K
🤖
eHand
6-DOF myoelectric prosthetic hand
Donor tier: $2K
🧠
eBCI-Lite
8-channel dry-electrode EEG headband
Donor tier: $10K
🌾
eFarm
Solar LoRaWAN soil sensor mesh
Donor tier: $1K
💧
eHydro
Water-quality monitoring buoy
Donor tier: $3K
🐝
eHive
Acoustic beehive monitor
Donor tier: $500
🚙
eRover-Mini
$400 autonomous research rover
Donor tier: $2K
🎓
eEdu-Kit
Classroom STEM dev board + curriculum
Donor tier: $1K
⚡
eMeshGrid
Off-grid micro-grid controller
Donor tier: $25K
🛰️
eCubeSat-1U
1U CubeSat with EmbeddedOS flight SW
Donor tier: $30K
BLOCK DIAGRAMS

Hardware Architecture

Interactive 3D block diagrams for key hardware product pipelines.

eHealth365 Sensor Pipeline
ECG → ADC → AI → Cloud
Cloud / Mobile App
EAI Inference
Signal Processing
ADC / Amplifier
Sensors
layered
eRadar360 Sensor Fusion
77GHz + LiDAR + Camera → AI
Decision Output
Sensor Fusion
Perception AI
Signal Processing
Sensor Array
layered
eAerospace Flight Control
Sensors → FCS → Mission Computer
Mission Computer
Flight Control
Sensor Fusion
Actuator Control
Hardware
layered

Run EmbeddedOS on Your Hardware

All hardware designs are MIT-licensed and available on GitHub. KiCad schematics, Altium designs, Gerber files, BOMs, and datasheets included.
